CS5566
DS806PP2
5
5/4/09
ANALOG CHARACTERISTICS
(CONTINUED)
T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- =
V2- = -2.5 V, ±5%; VL -VLR = 3.3 V, ±5%; VREF = (VREF+) - (VREF-) = 4.096V; MCLK = 8 MHz; SMODE = VL.;
BUFEN = V1+ unless otherwise stated. Connected per
.
5.
For optimum performance, VREF+ should always be less than (V+) - 0.2 volts to prevent saturation of the VREF+ input buffer.
6.
Specification is for MCLK = 8MHz and 5 kSps conversion rate. MCLK frequency and conversion rate affect power consumption.
See
Section 3.2 Power Consumption
for more details.
7.
Tested with 100 mVP-P on any supply up to 2 kHz. V1+ and V2+ supplies at the same voltage potential, V1- and V2- supplies at
the same voltage potential.
Parameter
Min
Typ
Max
Unit
Voltage Reference Input
Voltage Reference Input Range
(VREF+) – (VREF-)
(Note 5)
2.4
4.096
4.2
V
Input Capacitance
-
10
-
pF
CVF Current
VREF+ Buffer On (BUFEN = V+)
VREF+ Buffer Off (BUFEN = V-)
VREF-
-
-
-
3
1
1
-
-
-
μA
mA
mA
Power Supplies
Average DC Power Supply Currents (Note 6)
I
V1
I
V2
I
VL
-
-
-
-
-
-
5
0.6
0.4
mA
mA
mA
Peak DC Power Supply Currents
(Note 6)
I
V1
I
V2
I
VL
-
-
-
-
-
-
9
1.2
280
mA
mA
μA
Average Power Consumption
Normal Operation Buffers On
(Note 6) Buffers Off
Sleep (SLEEP = 0)
-
-
-
20
15
6
-
-
-
mW
mW
mW
Power Supply Rejection
(Note 7)
V1+ , V2+ Supplies
V1-, V2- Supplies
75
75
85
85
-
-
dB
dB
