1. CHARACTERISTICS AND SPECIFICATIONS
• Min / Max characteristics and specifications are guaranteed over the specified operating conditions.
• Typical characteristics and specifications are measured at nominal supply voltages and T
A
= 25°C.
• VLR = 0 V. All voltages with respect to 0 V.
ANALOG CHARACTERISTICS
T
A
= -40 to +85 °C; V1+ = V2+ = +2.5 V, ±5%; V1- = V2- = -2.5 V,
±5%; VL -VLR = 3.3 V, ±5%; VREF = (VREF+) - (VREF-) = 4.096V; MCLK = 8 MHz; SMODE = VL. BUFEN = V1+
unless otherwise stated. Connected per
Figure 8 . Bipolar mode unless otherwise stated.
1. No missing codes is guaranteed at 24 bits resolution over the specified temperature range.
2. One LSB is equivalent to (2 x VREF) ÷ 2 24 or (2 x 4.096) ÷ 16,777,216 = 488 nV.
3. Scales with MCLK.
4. Measured using an input signal of 1 V DC.
Parameter Min Typ Max Unit
Accuracy
Linearity Error - 0.0005 - ±%FS
Differential Linearity Error (Note 1) - ±0.1 - LSB
24
Positive Full-scale Error - 1.0 - %FS
Negative Full-scale Error - 1.0 - %FS
Full-scale Drift (Note 2) - 1 - PPM / °C
Bipolar Offset (Note 2) - ±500 - LSB
24
Bipolar Offset Drift (Note 2) - 1 - LSB / °C
Noise - 9.5 - μVrms
Dynamic Performance
Peak Harmonic or Spurious Noise 200 Hz, -0.5 dB Input - -115 - dB
Total Harmonic Distortion 200 Hz, -0.5 dB Input - -110 -100 dB
Signal-to-Noise 108 110 - dB
S/(N + D) Ratio -0.5 dB Input, 200 Hz
-60 dB Input, 200 Hz
-
- 109
50
-
- dB
dB
-3 dB Input Bandwidth (Note 3) - 21 - kHz
Analog Input
Analog Input Range (Differential) Unipolar
Bipolar
0 to +VREF
±VREF
V
V
Input Capacitance - 10 - pF
CVF Current (Note 4) AIN Buffer On (BUFEN = V+)
AIN Buffer Off (BUFEN = V-)
-
- 600
130 -
- nA
μA
Common Mode Rejection Ratio (DC to 2 kHz) -100 -110 - dB
