CS5521/22/23/24/28
20 DS317F8
1.2.3 Command Register Descriptions
READ/WRITE INDIVIDUAL OFFSET CALIBRATION REGISTER
Function : These commands are used to access each offset register separately. CS1 - CS0 decode the
registers accessed.
R/W (Read/Write)
0 Write to selected register.
1 Read from selected register.
CS[2:0] (Channel Select Bits)
000 Offset Register 1(All devices)
001 Offset Register 2 (All devices)
010 Offset Register 3 (CS5523/24/28 only)
011 Offset Register 4 (CS5523/24/28 only)
100 Offset Register 5 (CS5528 only)
101 Offset Register 6 (CS5528 only)
110 Offset Register 7 (CS5528 only)
111 Offset Register 8 (CS5528 only)
READ/WRITE INDIVIDUAL GAIN REGISTER
Function : These commands are used to access each gain register separately. CS1 - CS0 decode the reg-
isters accessed.
R/W (Read/Write)
0 Write to selected register.
1 Read from selected register.
CS[2:0] (Channel Select Bits)
000 Gain Register 1(All devices)
001 Gain Register 2 (All devices)
010 Gain Register 3 (CS5523/24/28 only)
011 Gain Register 4 (CS5523/24/28 only)
100 Gain Register 5 (CS5528 only)
101 Gain Register 6 (CS5528 only)
110 Gain Register 7 (CS5528 only)
111 Gain Register 8 (CS5528 only)
D7(MSB) D6 D5 D4 D3 D2 D1 D0
0 CS2 CS1 CS0 R/W 0 0 1
D7(MSB) D6 D5 D4 D3 D2 D1 D0
0 CS2 CS1 CS0 R/W 0 1 0
