for the 8051 microcontroller (8051_REGIN). Jumper J9 allows the 8051_REGIN supply to be sourced
from either the Vu+_EXT binding post (J6), +5V binding post (J3) or VD+_EXT binding post (J5).
1.6
Auto-boot Mode
With a jumper connection on J18 (AUTO-BOOT ENABLE), the CS5460A operates in auto-boot mode and
the CDB5460AU board operates as a stand-alone system without attaching it to a PC. When in auto-boot
mode, a hardware reset (press on S1) will cause the CS5460A to boot up using the serial data from the
serial EEPROM on the board (U10). When the CS5460A is in auto-boot mode, the SPI™ connections be-
tween the microcontroller and the CS5460A are removed and the GUI software can not access the
CS5460A registers and functions.
