CDB5460AU
28 DS487DBU1
CIRRUS LOGIC CDB5460AU_Rev_B.bom
BILL OF MATERIAL (Page 2 of 2)
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
33
020-03355-Z1
A
RES 301 OHM 1/3W ±1% NPb 1210 FILM
1
R25
DALE
CRCW1210301RFKEA
34
020-03378-Z1
A
RES 470 OHM 1/3W ±1% NPb 1210 FILM
4
R30 R31 R32 R33
DALE
CRCW1210470RFKEA
35
020-03539-Z1
A
RES 12.1k OHM 1/3W ±1% NPb 1210 FLM
1
R35
DALE
CRCW121012K1FKEA
36
020-02748-Z1
A
RES 15k OHM 1/4W ±1% 1206 NPb FILM
1
R37
DALE
CRCW120615K0FKEA
37
020-01473-Z1
A
RES 0 OHM 1/18W ±1% NPb 0805 FILM
12
R51 R52 R53 R54 R55 R56 R57 R58 R59 R60 R61 R62
DALE
CRCW08050000Z0EA
38
020-02273-Z1
A
RES 0 OHM 1/4W NPb 1206 FILM
1
R64
DALE
CRCW12060000Z0EA
39
120-00002-Z1
A
SWT SPST 130G 0/1 5mm TACT ESD NPb
1
S
1
ITT INDUSTRIES
PTS645TL50
INSTALL AFTER WASH PROCESS
40
110-00045-Z1
A
CON TEST PT .1"CTR TIN PLAT NPb BLK
16
TP1 TP2 TP9 TP10 TP11 TP12 TP13 TP20 TP21 TP22 TP23 TP24 TP25 TP26 TP27 TP30
KEYSTONE
5001
41
062-00124-Z1
A
IC PGM 128BIT SER EPROM NPb SOT23-5
1
U
1
MICROCHIP
24LC00-I/OT
PROGRAM AT TEST
42
061-00250-Z1
A
IC DIG LOW V BUF/LDRV 5V NPb SOIC20
1
U
2
FAIRCHILD SEMICONDUCTOR
74LCX760WMX
43
062-00079-Z1
A
IC PGM USB 16kB FLAS MCU NPb LQFP32
1
U
3
SILICON LABORATORIES INC
C8051F320-GQ
PROGRAM AT TEST
44
060-00061-Z1
A
IC LNR PREC V REF 2.5V NPb SO8
1
U
4
LINEAR TECH
LT1019CS8-2.5#PBF
45
061-00190-Z1
A
IC LOG UHS TINY DUAL BUF NPb SC70-6
1
U
5
FAIRCHILD SEMICONDUCTOR
NC7WZ07P6X
46
065-00161-Z2
C
IC CRUS PWR/ENERGY IC NPb SSOP24
1
U
6
CIRRUS LOGIC
CS5460A-BSZ/C
47
061-00002-Z1
A
IC LOG INV 5P UHS TINY NPb SOT23
1
U
8
FAIRCHILD SEMICONDUCTOR
NC7SZ04M5X
48
061-00219-Z1
A
IC LOG UHS TINY ANA SWT 6P NPb SC70
2
U9 U11
FAIRCHILD SEMICONDUCTOR
NC7SB3157P6X
49
062-00122-Z1
A
IC PGM EEPROM 512x8 SPI NPb SOIC8
1
U10
ATMEL
AT25040AN-10SU-2.7
PROGRAM AT TEST
50
080-00003-Z1
A
WIRE BPOST 1.5X.25 24/19 GA BLU NPb
4
XJ3 XJ4 XJ5 XJ6
SQUIRES
L-1.5X.25TX.25T_TYPE_E_
WIRES FOR BINDING POSTS
51
300-00025-Z1
A
SCREW 4-40X5/16" PH MACH SS NPb
4
XMH1 XMH2 XMH3 XMH4
BUILDING FASTENERS
PMSSS 440 0031 PH
SCREWS FOR STANDOFFS
52
135-00013-01
A
SKT PINCH CONTACT FOR SSOP24
0
XU6
ENPLAS
OTS-24(34)-0.65-01
DO NOT POPULATE
53
100-00049-Z1
A
XTL 4.0960MHZ HC49S 50ppm 50pF NPb
1
Y
1
CAL CRYSTAL
CCL-6S-4.0960C14F-R
54
070-00006-Z1
A
DIODE TR 6.8V 600W NPb AXL
3
Z1 Z2 Z3
LITTELFUSE
P6KE6.8
55
600-00176-Z2
B
SCHEM CDB5460AU-Z NPb
REF
CIRRUS LOGIC
600-00176-Z2
56
240-00176-Z1
B
PCB CDB5460A_61A_63 NPb
1
CIRRUS LOGIC
240-00176-Z1
57
603-00176-01
B
ASSY DWG PWA CDB5460A_61A_63
REF
CIRRUS LOGIC
603-00176-01
58
110-00013-Z1
D
CON SHUNT 2P .1"CTR BLK NPb
12
MOLEX
15-29-1025
REFER TO ASSEMBLY DRAWING FOR PLACEMENT LOCATIONS
59
422-00037-01
A1
LBL SUBASSY PRODUCT NUMBER
1
CIRRUS LOGIC
422-00037-01
REFER TO ASSEMBLY DRAWING FOR PLACEMENT LOCATION
60
020-01473-Z1
A
RES 0 OHM 1/18W ±1% NPb 0805 FILM
0
R34
DALE
CRCW08050000Z0EA
DO NOT POPULATE
61
110-00045-Z1
A
CON TEST PT .1"CTR TIN PLAT NPb BLK
0
TP7 TP8
KEYSTONE
5001
DO NOT POPULATE
62
312-00008-01
A
INSULATOR .312 x .145 FOR HC49U/US
1
XY1
ECS
700-9001
INSULATOR FOR Y1
