CDB5460AU
DS487DBU1
27
APPENDIX A. BILL OF MATERIALS
CIRRUS LOGIC
CDB5460AU_Rev_B.bom
BILL OF MATERIAL (Page 1 of 2)
Item
Cirrus P/N
Rev
Description
Qty
Reference Designator
MFG
MFG P/N
Notes
1
001-06872-Z1
A
CAP 0.1uF ±10% 50V NPb X7R 1206
6
C1 C18 C19 C21 C29 C30
KEMET
C1206C104K5RAC
2
001-02779-Z1
A
CAP 22pF ±5% 50V C0G NPb 0805
1
C
2
KEMET
C0805C220J5GAC
3
001-02189-Z1
A
CAP 0.1uF ±10% 16V X7R NPb 0603
5
C3 C4 C26 C32 C33
KEMET
C0603C104K4RAC
4
012-00010-Z1
A
CAP 47uF ±20% 16V NPb ELEC CASE C
4
C5 C8 C28 C31
PANASONIC
EEE1CA470WR
5
001-04344-Z1
A
CAP 0.1uF ±5% 50V X7R NPb 0805
7
C6 C7 C10 C11 C12 C15 C25
KEMET
C0805C104J5RAC
6
001-03266-Z1
A
CAP 220pF ±10% 50V X7R NPb 0805
4
C9 C17 C20 C24
KEMET
C0805C221K5RAC
7
001-06685-Z1
A
CAP 0.018uF ±10% 50V X7R NPb 1206
2
C13 C23
KEMET
C1206C183K5RAC
8
012-00012-Z1
A
CAP 10uF ±20% 16V ELEC NPb CASE A
3
C14 C22 C1000
PANASONIC
EEE1CS100SR
9
001-07078-Z1
A
CAP 1uF ±10% 25V X7R NPb 1206
1
C16
KEMET
C1206C105K3RAC
10
070-00055-Z1
A
DIODE ARRAY 5V (TVS) ESD NPb SOT143
1
D
1
LITTELFUSE
SP0503BAHTG
11
165-00004-Z1
A
LED SUP RED 1.7V 1mA 1.6MCD NPb SMD
6
D2 D3 D4 D5 D6 D7
CHICAGO MINIATURE
CMD28-21SRC/TR8/T1
12
115-00003-Z1
A
HDR 5x2 ML .1"CTR S GLD NPb
1
J
1
SAMTEC
TSW-105-07-G-D
13
110-00041-Z1
A
CON RA USB BLK NPb TH
1
J
2
AMP
292304-1
14
110-00010-Z1
A
CON BPOST 2" SILV NYLON INS RED NPb
3
J3 J5 J6
JOHNSON
COMPONENTS
111-0102-001
REQUIRES WIRE, 1.5L X 0.25T X
0.25T TYPE E 24/19 BLU SQUIRES
ELEC. INC.
15
110-00008-Z1
A
CON BPOST 2" SILV NYLON INS BLK NPb
1
J
4
JOHNSON
COMPONENTS
111-0103-001
REQUIRES WIRE, 1.5L X 0.25T X
0.25T TYPE E 24/19 BLU SQUIRES
ELEC. INC.
16
115-00016-Z1
A
HDR 3x2 ML .1"CTR 062 S GLD NPb
6
J8 J9 J17 J22 J24 J26
SAMTEC
TSW-103-07-G-D
17
115-00014-Z1
A
HDR 2x1 ML .1" 062BD ST GLD NPb TH
5
J10 J13 J15 J16 J18
SAMTEC
TSW-102-07-G-S
18
115-00013-Z1
A
HDR 2x2 ML .1"CTR .062BD S GLD NPb
1
J12
SAMTEC
TSW-102-07-G-D
19
110-00056-Z1
A
CON TERM BLOCK 2POS 5mm NPb BLU TH
1
J14
ON-SHORE
TECHNOLOGY
ED 100/2DS
20
110-00055-Z1
A
CON TERM BLCK 4 POS 5mm NPb BLU TH
2
J23 J27
ON-SHORE
TECHNOLOGY
ED 100/4DS
21
115-00009-Z1
A
HDR 3x1 ML .1" 062 ST GLD NPb TH
1
J25
SAMTEC
TSW-103-07-G-S
22
115-00031-Z1
A
HDR 11x2 ML .1"CTR 062 S GLD NPb
1
J40
SAMTEC
TSW-111-07-G-D
23
080-00004-Z1
A
WIRE JUMPER 2P 0.1" BRASS NPb TH
6
JP1 JP2 JP3 JP4 JP5 JP6
COMPONENTS
CORPORATION
TP-101-10
24
304-00001-Z1
A
SPCR STANDOFF 4-40 THR .875L AL NPb
4
MH1 MH2 MH3 MH4
KEYSTONE
1809
REQUIRES 4-40- PAN HEAD
SCREW
25
020-01848-Z1
A
RES 2k OHM 1/8W ±1% NPb 0805 FILM
12
R2 R3 R6 R7 R8 R14 R15 R16 R17 R29 R36
DALE
CRCW08052K00FKEA
26
020-01588-Z1
A
RES 10 OHM 1/8W ±1% NPb 0805 FILM
1
R
4
DALE
CRCW080510R0FKEA
27
020-01816-Z1
A
RES 1k OHM 1/8W ±1% NPb 0805 FILM
5
R5 R11 R12 R13 R18
DALE
CRCW08051K00FKEA
28
020-01930-Z1
A
RES 10k OHM 1/8W ±1% NPb 0805 FILM
0
R19
DALE
CRCW080510K0FKEA
DO NOT POPULATE
29
035-00005-Z1
A
RES POT 5k ±10% 25TURN TRIM NPb TH
0
R20
BOURNS
3296W-1-502LF
DO NOT POPULATE
30
020-01667-Z1
A
RES 49.9 OHM 1/8W ±1% NPb 0805 FILM
1
R21
DALE
CRCW080549R9FKEA
31
020-01905-Z1
A
RES 6.04k OHM 1/8W ±1% NPb 0805 FLM
0
R22
DALE
CRCW08056K04FKEA
DO NOT POPULATE
32
021-00759-Z1
A
RES 1k OHM 1/3W ±5% NPb 1210 FILM
4
R23 R24 R26 R28
DALE
CRCW12101K00JNEA
