DS514F2

19

CS4382

Soft Ramp

Soft Ramp allows level changes, both muting and attenuation, to be implemented by incrementally ramp-
ing, in 1/8 dB steps, from the current level to the new level at a rate of 1 dB per 8 left/right clock periods.

Soft Ramp on Zero Crossing

Soft Ramp and Zero Cross Enable dictates that signal level changes, either by attenuation changes or
muting, will occur in 1/8 dB steps and be implemented on a signal zero crossing. The 1/8 dB level change
will occur after a timeout period between 512 and 1024 sample periods (10.7 ms to 21.3 ms at 48 kHz
sample rate) if the signal does not encounter a zero crossing. The zero cross function is independently
monitored and implemented for each channel.

4.3.2

Single Volume Control (SNGLVOL)

Default = 0
0 - Disabled
1 - Enabled

Function:

The individual channel volume levels are independently controlled by their respective Volume Control
Bytes when this function is disabled. The volume on all channels is determined by the A1 Channel Vol-
ume Control Byte, and the other Volume Control Bytes are ignored when this function is enabled.

4.3.3

Soft Volume Ramp-Up After Error (RMP_UP)

Default = 0
0 - Disabled
1 - Enabled

Function:

An un-mute will be performed after executing a filter mode change, after a LRCK/MCLK ratio change or
error, and after changing the Functional Mode. When this feature is enabled, this un-mute is effected,
similar to attenuation changes, by the Soft and Zero Cross bits in the Mode Control 3 register. When dis-
abled, an immediate un-mute is performed in these instances.

Note:

For best results, it is recommended that this feature be used in conjunction with the RMP_DN bit.

4.3.4

Mutec Polarity (MUTEC+/-)

Default = 0
0 - Active High
1 - Active Low

Function:

The active polarity of the MUTEC pin(s) is determined by this register. When set to 0 (default), the MUTEC
pins are high when active. When set to 1 the MUTEC pin(s) are low when active.

Note:

When the onboard mute circuitry is designed for active low, the MUTEC outputs will be high (un-

muted) for the period of time during reset and before this bit is enabled to 1.
