3. Commissioning and operation
3.1 Preparation
3.1.1 Setting up the device
■ Set up the hand spindle pump on a solid surface.
Avoid unsafe mounting conditions. If necessary, it can be secured by mounting on
a baseplate or workbench using appropriate screws. Two drillings (Ø 6.4 mm) are
available on the front flange for this purpose.
■ Place the star handle with knobs onto the spindle pump.
Ensure that the spring-loaded thrust pad engages into the star handle bushing.
3.1.2 Filling in of operating liquid (first commissioning)
As an operating liquid only the following are suitable for the
CPP1000-M/-L:
■ Mineral oil based hydraulic fluid
■ Clean water, free of calcium-carbonate / scale
Distilled water and water-based hydraulic fluids are not
suitable!
Other pressure transmitting media are available on request.
Fill the hand spindle pump with a suitable operating liquid as follows:
■ Turn the spindle completely clockwise.
■ Open the shut-off valve and unscrew it completely, then remove the top cover of the
reservoir.
■ Pour the operating liquid carefully and slowly, alternating between both pressure
connections. You can monitor how the operating liquid settles into the reservoir.
Pour the liquid into the pressure connections until the reservoir is ½ to ¾ full.
■ Place the top cover of the reservoir back on and reattach the shut-off valve.
