WIKA CPP1600-X - Manual (Page 19)

11178035 12/2010 GB/D/F/E
WIKA Operating Instructions Hand Spindle Pump
Hand Spindle Pump
CPP1000-M/-L
19
7. Specifications
CPP1000-M CPP1000-L
Pressure range bar 0 ... 1000
Medium
Mineral oil based hydraulic fluid / clean water, free of
calcium-carbonate / scale 1)
Pressure connections 2 x G ½“ female thread, rotating, with o-ring
Distance of the test connections mm 200 115
Liquid container cm³ 110 55
Piston diameter mm 8
Swept volume per revolution cm³ approx. 0.1
Overall swept volume cm³ approx. 3.9
Pressure fine adjustment option, see accessories
lateral fine adjustment
valve
Required moment at
- 250 bar
Nm 2.0
- 500 bar Nm 4.0
- 1000 bar Nm 8.0
Material
- Piston
Stainless steel
- Cylinder Brass
- Rear flange Aluminium
- Sealing gaskets FKM and NBR; optional EPDM
Stationary fastening two through holes in the front flange Ø 6.4 mm
Dimensions mm 420 (L) x 280 (W) x 103 (H) 420 (L) x 240 (W) x 103 (H)
Weight kg 6.3 5,6
1) Other pressure transmitting media on request.
