WIKA Operating Instructions Hand Spindle Pump
Hand Spindle Pump
CPP1000-M/-L
17
For mounting you need the following tools:
■
Allen wrench 8 mm
■
Flat wrench SW 27
■
Tweezers
■
1 piece valve with integrated seals
Side view of hand spindle pump showing the blind plug with hexagon socket
Open the blind plug using an 8 mm allen wrench
and dismount the blind plug completely.
blind plug with
hexagon socket
GB
