WIKA CPP1600-X - Manual (Page 3)

1. General 4
1.1 General safety instructions 4
2. Product description 6
2.1 General product information 6
2.2 Arrangement of control elements 6
3. Commissioning and operation 7
3.1 Preparation 7
3.1.1 Setting up the device 7
3.1.2 Filling in of operating liquid 7
3.1.3 Connecting the pressure measuring instruments (reference and test
specimen)
8
3.1.4 Venting the system 9
3.2 Operation 10
3.3 Handling the CPP1000-M/-L with shut-off valve for test connection 11
3.4 Disassembly 13
4. Troubleshooting measures 13
5. Maintenance and care 15
5.1 Wear parts 15
5.2 Changing the operating liquid 15
6. Mounting instruction for shut-off valve for test connection and
fine adjustment valve
16
7. Specifications 19
8. Dimensions 20
9. Order data / Accessories 21
10. Addresses 83
11178035 12/2010 GB/D/F/E
WIKA Operating Instructions Hand Spindle Pump
Hand Spindle Pump
CPP1000-M/-L
3
Information
This symbol provides you with information, notes and tips.
Warning!
This Symbol warns you against actions that can cause injury
to people or damage to the instrument.
Contents
GB
