Wd-sd, Wiring diagram warranty, Spot detection wd-sd – Light Engineered Displays WD-SD Series - Spot Detector User Manual
Page 2
SPOT DETECTION
WD-SD
WD-SD
SERIES
Wiring Diagram
Warranty
To next detector
From power supply
Probe
3
4
5
1
2
6
7
8
To Annunciator
TYPICAL HOOK-UP
ALTERNATE HOOK-UP FOR FIRE & SECURITY PANELS
+
–
+
Power
Alarm Zone
Probe
3
4
5
1
2
7
+
Alarm initiating
6
8
Power
Alarm Zone
Probe
3
4
5
1
2
7
+
Trouble initiating
6
8
Alarm Zone
Probe
3
4
5
1
2
7
6
8
+
NOTE: 1. Unit is powered directly from Alarm Zone
2. Relay requires 20 ma. to activate.
+
–
Probe
Contact
24 vdc
Power
We will repair or replace any defective unit within one year of purchase except in cases of abuse,
misuse or incorrect wiring.
There are no warranties which extend beyond the use of this product. There is no warranty of fitness
for a particular purpose. In no event shall AquaALERT of Light Engineered Displays, Inc. be liable to
the purchaser or any other party for consequential or incidential damages.
AquaALERT Water Sensing Products, Division of Light Engineered Displays, Inc.
