Contents
ii
Figures
Figure 1: VS-81SP 8 x 1 Loudspeaker Switcher Functions 4
Figure 2: Connecting the VS-81SP – 1 Amplifier to 8 Speaker Pairs 8
Figure 3: Connecting the VS-81SP – 8 Amplifiers to 1 Speaker Pair 8
Figure 4: Connecting a PC Without Using a Null-modem Adapter 9
Figure 5: Controlling via RS-485 10
Figure 6: SETUP DIP-switches (Factory Default for Stand-Alone MACHINE # 1) 10
Figure 7: DIP-switch Settings on 4 VP-81SP Units 12
Figure 8: Cascading 3 VP-81SP Units 14
Figure 9: Addressing 3 Cascaded VP-81SP Units 14
Figure 10: Connecting a Remote Mechanical Switcher Unit to the VP-81SP 15
Figure 11: Connecting a Remote Unit to a Cascaded Set of Three VP-81SP Units 16
Figure 12: Splash Screen 20
Figure 13: Atmel – Flip Window 20
Figure 14: Device Selection Window 21
Figure 15: Device Selection Window 21
Figure 16: Loading the Hex 22
Figure 17: RS-232 Window 22
Figure 18: Atmel – Flip Window (Connected) 23
Figure 19: Atmel – Flip Window (Operation Completed) 24
Tables
Table 1: VS-81SP 8 x 1 Loudspeaker Switcher Functions 5
Table 2: DIP-switch Definitions 11
Table 3: MACHINE # DIP-switch Settings 11
Table 4: MACHINE ADDRESS # DIP-switch Settings 13
Table 5: VS-81SP Technical Specifications 18
Table 6: VS-81SP Hex Table 25
Table 7: Protocol Definitions 25
