Operating the VS-81SP 8 x 1 Loudspeaker Switcher
17
17
7 Operating the VS-81SP 8 x 1 Loudspeaker Switcher
You can operate your VS-81SP using:
• The front panel buttons
• RS-232/RS-485 serial commands transmitted by a touch screen
system, PC, or other serial controller
• The infrared remote control transmitter
7.1 Using the Front Panel Buttons
To choose an input to switch to the output, press the appropriate IN/OUT
SELECTOR button.
7.2 Using Serial Commands
To operate your device using serial commands, you need to install Kramer's
control software that can be downloaded from the Kramer Electronics Web
site
1
For an explanation of all control commands, see section
.
11 .
7.3 Operating via the Infrared Remote Controller
You can use the RC-IR2 IR transmitter to control the machine via the
built-in IR receiver on the front panel or, instead, via an optional external IR
receiver
2
. The external IR receiver can be located 15 meters away from the
machine. This distance can be extended to up to 60 meters when used with
three extension cables
3
Before using the external IR receiver, be sure to arrange for your Kramer
dealer to insert an internal IR connection cable
17F
4
, which is required so that
the REMOTE IR 3.5mm connector can be used. Connect the external IR
receiver to the REMOTE IR 3.5mm connector.
To operate your device using the infra-red remote controller, see the User
Manual packed with the remote controller.
1 Download Kramer control software from our Web site at http://www.kramerelectronics.com
2 P/N: 95-0104050
3 P/N: 95-0103050
4 P/N: 505-70434010-S
