Upgrading the VS-81SP Firmware
19
19
9.2 Connecting a PC to the RS-232 Port
To connect a PC to the RS-232 port of the VS-81SP:
1. Power the VS-81SP OFF.
2. Connect a serial cable from the VS-81SP RS-232 9-pin D-sub rear panel
port to a PC as explained in section 6.1 .
3. Do the following according to the sequence below:
• Turn the POWER switch ON
• Set DIP 9 ON
• Set DIP 10 ON
• Set DIP 12 ON
• Set DIP 11 ON
• After a few seconds, set DIP 11 OFF
The front panel buttons may illuminate erratically. This is
normal, and can be ignored.
9.3 Installing the Firmware
To install the firmware, perform the following steps:
1. Double-click the desktop icon Shortcut to FLIP.EXE.
The Splash screen appears
21F
1
:
1 The screens appearing in this manual are examples of the process. The actual screens may differ in their content.
