Connecting the VS-81SP 8 x 1 Loudspeaker Switcher
7
7
6
Connecting the VS-81SP 8 x 1 Loudspeaker Switcher
To connect the VS-81SP, as shown in
, do the following
1. Connect the input source (for example, the speaker outputs from a power
amplifier) to the OUT/IN terminal block connectors.
:
2. Connect the IN/OUT connectors to the speaker pairs (up to eight).
3. As an option you can connect a PC and/or controller to the:
4. Set the DIP-switches (see section
).
5. If required, connect remote contact-closure switches to the REMOTE
terminal block connector (see section
6. Connect the power cord to the power socket and connect the power cord to
the mains electricity.
Note: In a reverse configuration (see
), you can connect up to eight
power amplifiers to the IN/OUT input connectors and one speaker pair to
the OUT/IN output connector.
1 Switch OFF the power on each device before connecting it to your VS-81SP. After connecting your VS-81SP, switch on its
power and then switch on the power on each device
