26
VS-44HDCP - Protocol 3000
12
Protocol 3000
By default, the VS-44HDCP is set to Protocol 2000 (see
Section
but is also
compatible with Kramer’s protocol 3000 (see
Section
Note that the VS-44HDCP needs to be set to protocol 2000 in order to
use the IR remote control.
Section
describes how to switch between protocol 3000 and protocol 2000.
The VS-44HDCP can be operated using serial commands from a PC, remote
controller or touch screen using the Kramer Protocol 3000.
This section describes:
Kramer Protocol 3000 syntax (see
Section
Kramer Protocol 3000 commands (see
Section
12.1
Kramer Protocol 3000 Syntax
12.1.1
Host Message Format
Start
Address (optional)
Body
Delimiter
#
device_id@
Message
CR
12.1.1.1 Simple Command
Command string with only one command without addressing:
Start
Body
Delimiter
#
Command SP
Parameter_1,Parameter_2,…
CR
12.1.1.2 Command String
Formal syntax with commands concatenation and addressing:
Start
Address
Body
Delimiter
#
device_id@
Command_1 Parameter1_1
,Parameter1_2,…|
Command_2
Parameter2_1,Parameter2_2,…|
Command_3
Parameter3_1,Parameter3_2,…|…
CR
