VS-44HDCP - Default Communication Parameters

23

23

10

Default Communication Parameters

RS-232

Protocol 2000 (Default)

Protocol 3000

Baud Rate:

9600

Baud Rate:

9600

Data Bits:

8

Data Bits:

8

Stop Bits:

1

Stop Bits:

1

Parity:

None

Parity:

None

Command Format:

HEX

Command Format:

ASCII

Example (Output 1 to Input 1): 0x01, 0x81,

0x81, 0x81

Example (Output 1 to Input 1): #VID1>1

Switching Protocol

P2000 -> P3000

P3000 -> P2000

Command:

0x38, 0x80, 0x83, 0x81

Command:

#P2000

Front Panel:

Press and hold Output 1 and

Output 3 simultaneously

Front Panel: Press and hold Output 1 and

Output 2 simultaneously

Ethernet

IP Address

192.168.1.39

TCP Port

5000 or 10001 or 50000

Subnet Mask

255.255.255.0

UDP Port

50000
