14

VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher

6.5.3

Acquiring the Default EDID

To store the default EDID on a selected input (for example, IN 2):

1. Press the EDID and STO buttons simultaneously and hold them for 3

seconds.

Both buttons flash.

2. Press the SELECT IN button to which the EDID will be copied (for example,

IN 2).

The selected input number flashes on the display.

3. Press the OFF button until a "0" (zero) appears on the display.

4. Press the EDID button.

The default EDID is stored on the selected input when the display returns to

normal.

6.6

Resetting the Ethernet Configuration to Default Values

Power cycle the unit while holding in the Factory Reset button, located on the rear

panel of the unit.
