8 VS-44HDCP - Connecting the VS-44HDCP
5 Connecting the VS-44HDCP
Always switch off the power to each device before connecting it to your
VS-44HDCP. After connecting your VS-44HDCP, connect its power
and then switch on the power to each device.
To connect the VS-44HDCP as illustrated in the example in Figure 3 :
1. Connect up to four DVI sources (for example, DVD players and/or Blu-ray
disc players) to the IN DVI connectors.
2. Connect the OUT DVI connectors to up to four DVI acceptors (for example,
DVI and/or LCD displays).
3. If required, connect a PC and/or controller to the RS-232 port (see
Section
7.1
) and/or the Ethernet port (see Section
7.2
).
4. Connect the power cord (not shown in Figure 3 ).
5. If required, acquire the EDID (see Section 6.5 ).
