Technical Specifications
35
10 Technical Specifications
Table 13 includes the technical specifications:
Table 13: Technical Specifications
1
of the VS-44HC
Video Components
INPUTS: 4 sets of component video (Y, Pb/Cb, Pr/Cr) 1Vpp, 0.7Vpp, 0.7Vpp /
75 on RCA connectors
OUTPUTS: 4 sets of component video (Y, Pb/Cb, Pr/Cr) 1Vpp, 0.7Vpp, 0.7Vpp /
75 on RCA connectors
MAX. OUTPUT LEVEL: 2.3Vpp
BANDWIDTH (-3dB): 200MHz, Fully Loaded
DIFF. GAIN: 0.08%
DIFF. PHASE: 0.77 Deg
K-FACTOR: <0.05%
S/N RATIO: 73dB weighted
CROSSTALK (all hostile): -53dB @ 5MHz
COUPLING: DC
Audio Components
INPUTS: 4 S/PDIF digital audio, on RCA connectors; 1 TOSLINK optical
OUTPUTS: 4 S/PDIF digital audio, on RCA connectors; 1 TOSLINK optical
S/PDIF SAMPLE RATE: Up to 192kHz
RESOLUTION: Up to 24 bits
JITTER: <1.5ns (50Hz to 100kHz) without delay, <3.5ns (50Hz to 100kHz)
with delay
MAXIMUM DELAY TIME FOR
CHANNEL 2:
32kHz – 999ms; 44.1kHz – 720ms; 48kHz – 680ms; 96kHz – 340ms
DELAY RESOLUTION: 1ms
General
CONTROLS: Front panel buttons, Ethernet, RS-232, RS-485, IR remote control
POWER SOURCE: 100-240 VAC, 50/60 Hz; 90mA switching power supply
DIMENSIONS: 19-inch (W), 7-inch (D) 1U (H) rack-mountable
WEIGHT: 2.7 kg (6 lbs.) approx.
ACCESSORIES: Power cord, Null modem adapter, Windows®-based Kramer control
software, Windows®-based Ethernet Configuration Manager and Virtual
Serial Port Manager, Infra-red remote control transmitter
1 Specifications are subject to change without notice
