Technical Specifications
31
9 Technical Specifications
Table 10 includes the technical specifications:
Table 10: Technical Specifications
1
of the VP-81xl/VP-161xl/VP-321xl
VP-81xl : 8 analog red, green, blue signals - 0.7Vpp / 75 , H & V syncs,
TTL level on HD15F connectors
8 balanced audio stereo signals, + 4dBm typ. on detachable
terminal blocks
VP-161xl : 16 analog red, green, blue signals - 0.7Vpp / 75 , H & V syncs,
TTL level on HD15F connectors
16 balanced audio stereo signals, + 4dBm typ. on detachable
terminal blocks
INPUTS:
VP-321xl : 32 analog red, green, blue signals - 0.7Vpp / 75 , H & V syncs,
TTL level on HD15F connectors
32 balanced audio stereo signals, + 4dBm typ. on detachable
terminal blocks
OUTPUTS: 1 analog red, green, blue signals - 0.7Vpp / 75 , H & V syncs, TTL level on an
HD15F connector
1 balanced audio stereo signal, + 4dBm typ. on detachable terminal blocks
MAX. INPUT/OUTPUT
LEVEL:
VIDEO: 2Vpp AUDIO: 26dBm
VP-81xl : VIDEO: >500MHz
VP-161xl : VIDEO: >500MHz
BANDWIDTH (-3dB):
VP-321xl : VIDEO: >500MHz
AUDIO: 100kHz
S/N RATIO: VIDEO: 73dB AUDIO: >83dB
CROSSTALK (all
hostile):
VIDEO: -47 dB@ 5MHz AUDIO: -65dB@ 1kHz
CONTROLS: Front panel selector switches; RS-232, RS-485; IR remote control; detachable
terminal blocks for remote dry-contact switches
COUPLING: VIDEO: DC AUDIO: DC
AUDIO THD + NOISE: <0.025%
AUDIO 2nd HARMONIC: <0.003%
POWER SOURCE:
230 VAC, 50/60 Hz, (115VAC, U.S.A.) 12VA max
VP-81xl : 19-inch (W), 7-inch (D) 1U (H) rack-mountable
VP-161xl : 19-inch (W), 7-inch (D) 2U (H) rack-mountable
DIMENSIONS:
VP-321xl : 19-inch (W), 7-inch (D) 4U (H) rack-mountable
VP-81xl 2.7 kg (6 lbs.) approx
VP-161xl : 3.4 kg (7.5 lbs.) approx
WEIGHT:
VP-321xl: 5.5 kg (12.2 lbs.) approx
ACCESSORIES: Power cord, Null modem adapter, Windows®-based Kramer control software,
Infra-red remote control transmitter
1 Specifications are subject to change without notice
