Connecting an XGA / Audio Switcher
21
You can also connect remote contact-closure switches to the REMOTE terminal
block connectors (according to Table 9). The example in Figure 13 illustrates
how to connect remote contact-closure switches to the REMOTE terminal block
connectors on a set of three looped VP-81xl units:
1 ............
............
2
VP-81xl Unit # 1
VP-81xl Unit # 2
VP-81xl Unit # 3
7 8
15 14 ............
............
9
21 ............
............
16 22 G
Figure 13: Connecting a Remote Unit to a Cascaded Set of Three VP-81xl Units
