Technical Specifications
28
Table 16: Technical Specifications of the TP-121/TP-122/TP-123/TP-124
TP-121 TP-122 TP-123 TP-124
INPUTS: VIDEO: 1
VGA/UXGA on a
15-pin HD
connector
AUDIO: 1 audio
ANALOG 3.5mm
mini jack
1 RJ-45 LINE IN
connector
VIDEO: 1
VGA/UXGA on a
15-pin HD
connector
AUDIO: 1 audio
ANALOG 3.5mm
mini jack
1 RJ-45 LINE IN
connector
OUTPUTS: 1 RJ-45 OUT
connector
VIDEO: 1
VGA/UXGA on a
15-pin HD
connector
AUDIO:
1 audio S/PDIF
RCA connector
1 audio ANALOG
3.5mm mini jack
1 RJ-45 OUT
connector
VIDEO: 1
VGA/UXGA on a 15-
pin HD connector
AUDIO:
1 audio S/PDIF
RCA connector
1 audio ANALOG
3.5mm mini jack
MAX. OUTPUT LEVEL: VIDEO: 1V
AUDIO: 2.5V
VIDEO: 1V
AUDIO: 2.5V
CONTROLS: Level: –7.5dB to
+4.4dB,
EQ.: 0dB to
+33dBm (130m) @
50MHz
RS-232 2 PIN
Terminal Block
RS-232 2 PIN
Terminal Block
Level: –7.5dB to
+4.4dB,
EQ.: 0dB to +33dBm
(130m) @ 50MHz
BANDWIDTH (-3dB) 1 AUDIO: 20Hz – [email protected] :
S/N RATIO: VIDEO: 58dB unweighted, 68.3dB @5MHz weighted
AUDIO: <–80dB
TOTAL GAIN: AUDIO: Analog/analog: 0dB; Analog/SPDIF: –12dBFS
COUPLING: AC
TND+N: AUDIO: <0.01%
POWER SOURCE: 12V DC 130mA (TP-121)
12V DC 190mA (TP-122)
12V DC 540mA (TP-121/TP-122 pair
when powered from TP-121 via Power
Connect)
12V DC 390mA (TP-121/TP-122 pair
when powered from TP-122 via Power
Connect)
12V DC 130mA (TP-123)
12V DC 200mA (TP-124)
12V DC 550mA (TP-123/TP-124 pair
when powered from TP-123 via Power
Connect)
12V DC 390mA (TP-123/TP-124 pair
when powered from TP-124 via Power
Connect)
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: Power supply
OPTIONS: 19” rack mount
1 For the Transmitter/Receiver pair
