Connecting the XGA/Audio/Data Line Transmitter/Receiver
20
the TP-123 RS-232 port 1
2. On the TP-124, connect:
 The XGA OUT 15-pin HD (F) connector to a display
 The S/PDIF Audio OUT RCA connector to a digital AV
Receiver (leave the ANALOG Audio OUT 3.5mm mini jack
unconnected)
 An RS-232 cable with a 2 PIN terminal block connector at one
end to the TP-124 RS-232 port 1 , and a 9-pin D-sub connector at
the other end to the RS-232 port on an RS-232 controllable
device (for example, a switcher)
3. Connect the Line OUT RJ-45 connector on the TP-123 to the LINE IN
RJ-45 connector on the TP-124, via UTP cabling 2
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity on both
(with a range of more
than 300ft (>100m)).
3
5. On the TP-124:
the TP-123 and the TP-124.
 Adjust 4
 If necessary, set the H SYNC and V SYNC switches
the video output signal level and/or cable compensation
equalization level, if required
5
1 As defined in
, on the
underside
Figure 16 and Table 13
2 For details of how to wire a CAT 5 LINE IN/LINE OUT RJ-45 connector, see section 8.1
3 If you cannot connect the power to both the TP-123 and TP-124, you can just connect the power to any one unit
4 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level
5 By default, both switches are set down (for negative V SYNC and H SYNC polarity)
