12 Technical Specifications
includes the technical specifications of the TP-104,
includes the technical specifications of the TP-105, and
the technical specifications of the TP-121, TP-122, TP-123, and TP-124:
Table 14: Technical Specifications
of the TP-104
TP-104
INPUTS:
1 VGA/UXGA on a 15-pin HD connector
OUTPUTS:
4 RJ-45 OUT connectors
MAX. OUTPUT LEVEL: 1.4Vpp
BANDWIDTH (-3dB)
>150MHz, up to 1080p
DIFF. GAIN
3.2%
DIFF. PHASE
0.5Deg
K-FACTOR
<0.05%
S/N RATIO
80dB
CONTROLS
EQ.: 0 to 33dB; LEVEL: –7.5dB to 4.4dB
COUPLING
AC
POWER SOURCE:
12V DC 180mA
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply
Table 15: Technical Specifications of the TP-105
TP-105
INPUTS:
1 RJ-45 OUT connector
OUTPUTS:
2 RJ-45 OUT connectors
MAX. OUTPUT LEVEL: 1.6Vpp
BANDWIDTH (-3dB)
Appropriate for VGA-UXGA, up to 1080p
:
DIFF. GAIN
3.7%
DIFF. PHASE
0.5Deg
K-FACTOR
<0.05%
S/N RATIO
69dB
CONTROLS
EQ.: 0 to 4.4dB @ 50MHz; LEVEL: –5.5dB to 1.4dB
COUPLING
AC
POWER SOURCE:
12V DC 220mA
DIMENSIONS:
12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT:
0.3kg (0.67lbs) approx.
ACCESSORIES:
Power supply
1 Specifications are subject to change without notice
2 With 60m CAT 5 cable
3 For the TP-104 Transmitter/ TP-120 Receiver SETUP
4 The HD resolutions apply to the HD version of the machine
5 For the PT-110 to TP-105 to TP-120 Receiver SETUP
