Connecting the XGA/Audio Line Transmitter/Receiver
17
17
8
Connecting the XGA/Audio Line Transmitter/Receiver
You can use the TP-121 and TP-122 to configure an XGA/Audio Line-
to-Twisted Pair Transmitter and Receiver system.
To connect the TP-121 XGA/Audio Line Transmitter with the TP-122
XGA/Audio Line Receiver, as the example in
following:
1. On the TP-121, connect the XGA source (for example, a laptop’s graphics
card) to the XGA INPUT 15-pin HD (F) connector and an audio source to
the AUDIO IN 3.5mm mini jack, for example, using a Kramer
C-GMA/GMA cable (VGA 15-pin HD (M) +Audio jack to VGA 15-pin
HD (M) +Audio jack)1
2. On the TP-122, connect the XGA OUT 15-pin HD (F) connector to the
XGA acceptor (for example, a display), and connect the AUDIO OUT
S/PDIF RCA connector to the digital audio acceptor (for example, an AV
Receiver), and the ANALOG 3.5mm mini jack to the analog audio acceptor
(for example, a stereo audio recorder).
. Alternatively, you can connect an XGA source to
the XGA INPUT 15-pin HD (F) connector, and a separate audio source to
the AUDIO IN 3.5mm mini jack.
3. Connect the LINE OUTPUT RJ-45 connector on the TP-121 to the LINE
IN RJ-45 connector on the TP-122, via UTP cabling (with a range of more
than 300ft (>100m)), see section
4. Connect the 12V DC power adapter to the power socket and connect the
adapter to the mains electricity on both
5. On the TP-122:
the TP-121 and the TP-122.
The signal from the XGA source is transmitted via CAT 5 cable, decoded
and converted at the XGA OUT 15-pin HD (F) connector to the XGA
acceptor.
Adjust
If necessary, set the H SYNC and V SYNC switches
the video output signal level and/or cable compensation
equalization level, if required
1 Not supplied. The complete list of Kramer cables is on our Web site
, on the
underside
2 If you cannot connect the power to both the TP-121 and TP-122, you can just connect the power to the TP-122
3 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level
4 By default, both switches are set down (for negative V SYNC and H SYNC polarity)
