Passive CCTV Hub Plus Installation Guide
Page 6
3.
Installation Procedure
3.1.
Parts List
The Passive CCTV Hub Plus comes with the following parts. Please verify
that all pieces are present before proceeding.
• Base Unit (Factory configuration: Power-Thru Mode (500022)
• 16-channel power cable assembly.
• Installation Guide
3.2.
Product Overview
The external connections of the Passive CCTV Hub Plus are detailed in the
following diagrams. Please familiarize yourself with them before installing the
unit.
Figure 1: Front panel
Figure 2: Rear panel
