© MuxLab Inc. Passive CCTV Hub Plus Installation Guide
Page 4
1.
Overview
1.1. Description
The Passive CCTV Hub Plus (500134) allows video, remote power and PTZ
control to be transmitted via one Cat5e/6 cable, thus eliminating the need to
install multiple cables for more efficient cabling in the security video
environment. The hub features a detachable, factory-installed, 16-channel
power cable assembly that allows the hub to be connected to a 16-channel
CCTV power supply for greater ease of installation. In order to connect
remote power to the hub, the 16-channel power cable assembly included with
the hub must be used.
The Passive CCTV Hub Plus works in conjunction with MuxLab’s 500000,
500009, 500015, 500022, 500023, 500024, 500029, 500120, 500122 and
500130. The product features a port switch to set the unit to Power-Thru or
Pass-Thru mode.
1.2. Features
• Port switch to set unit to Pass-Thru Mode (500022) or Power-Thru Mode
(500024/500029)
• Includes 16-channel power cable assembly (packaged seperately)
• Pin configuration chart on unit
• Space efficient, rack-mountable
