Muxlab LongReach II Active CCTV Receiver Hub User Manual
Page 12

© MuxLab.
LongReach II Active CCTV Receiver Hub Installation Guide
Page 12
2. If the product is to be installed on a desk, then
remove the rackmount brackets with a standard
Philips screwdriver and store the brackets for future
use. Peel the backing off the rubber standoffs and
affix them to the corners underneath the base of the
unit.
3. Please familiarize yourself with the connectors on
the front and rear panel of the hub. The following
diagrams show the front and rear views.
Front and rear views - 500126
Front and rear views - 500127
