Pre-installation checklist – Muxlab Active VGA Balun II Kit User Manual
Page 9
© MuxLab Inc. Active VGA Balun II Family Installation Guide
Page 9
3.3.
Pre-Installation Checklist
There are two (2) components: the transmitter and the
receiver.
1. The transmitter is connected to the video source,
usually a PC, by a VGA jumper cable (not included).
2. A local monitor can be connected to the transmitter
by a VGA jumper cable (not included).
3. The transmitter is connected to the receiver by
Category 5e/6 (or higher) UTP cable (not included).
4. The receiver is connected to the display equipment,
usually a projector or screen, by a VGA jumper
cable (not included) or directly on the equipment.
5. Verify that the desired image resolution is within the
specification of the Active VGA Balun II Kit.
