© MuxLab Inc. Active VGA Balun II Family Installation Guide
Page 7
3.
Installation Procedure
3.1.
Parts List
The Active VGA Balun II Kit (500140) comes with the
following parts. Please verify that all pieces are present
before proceeding.
• Transmitter
• Receiver
• Two (2) External Power Supplies (12 VDC, 0.5A)
• Blades for North America, Continental Europe and
UK
• Installation Guide
The Active VGA Balun Receiver (500142) and Power
Supply (500144) are also sold separately for use with
the VGA Hub (500150).
VGA jumper cables and Category 5e/6 cable are not
included.
