Muxlab Active VGA Balun II Kit - Manual (Page 6)

© MuxLab Inc. Active VGA Balun II Family Installation Guide
Page 6
2.
Technical Specifications
Environment VGA. VESA VP&D 1.0, VIP ver 2.0. DDC1 and DDC1.
Devices PCs, laptops, CRT monitors, LCD monitors, plasma screens, DLP
projectors.
Transmission Transparent to the user.
Bandwidth Up to 220 MHz (1920 x 1200 resolution), 1080p
Input Impedance HD15; 75 ohms
Output Impedance - Cat5: 100 ohms
Connectors –
Transmitter VGA/Component Input (PC): DB15HD-F
VGA/Component Output (Local Monitor): DB15HD-F
VGA/Component Output (Cat5): RJ45 shielded
Connectors –
Receiver VGA/Component Input (Cat5): RJ45 shielded
VGA/Component Output (Display): DB15HD-M
Maximum Distance –
Remote Power 150 ft (46m) (Tx Balun unpowered, Rx balun powered)
150 ft (46m) (Tx Balun powered, Rx balun unpowered)
Max. Distance –
VGA via Cat 5 (or
better) Twisted Pair 640 x 480 (VGA): 1000 ft (305m)
800 x 600 (SVGA): 1000 ft (305m)
1024 x 768 (XGA): 1000 ft (305m)
1280 x 1024 (SXGA): 850 ft (260m)
1600 x 1200 (UXGA): 800 ft (245m)
1366 x 768 (WXGA): 850 ft (260m)
1680x1050 (WSXGA): 850 ft (260m)
1920 x 1200 (WUXGA):600 ft (180m)
Max Distance –
Component Video
(YPbPr) via Cat 5 (or
better) Twisted Pair 480i/p: 1,000 ft (305 m)
1080i: 850 ft (260 m)
1080p: 600 ft (180 m)
* VGA-to-component video cables required (not included)
RJ45 Pin Configuration
Reverse Polarity Sensitive
Use EIA/TIA 568 A or B,
straight-through wiring
Red: Pin 7 (R) Pin 8 (T)
Green: Pin 3 (R) Pin 6 (T)
Blue: Pin 1 (R) Pin 2 (T)
DDC/Remote Power: Pin 4 (R) Pin 5 (T)
Gain Adjustment Gain control via DIP switches on receiver (factory default setting: all OFF)
LED Indicators Tx Balun: Power: One (1) green LED Sync: One (1) green LED
Rx Balun: Power: One (1) green LED
Cable Category 5 or better twisted pair cable.
Transmitter requires additional VGA jumper cables (not included)
Power Supplies 110-240V/12VDC/0.5. Removable AC blades included for North
America and Continental Europe.
12VDC power jacks.
Temperature Operating: 0º to 40º C. Storage:-10º to 70º C.
Humidity: up to 95% non-condensing.
Enclosure Black. ABS fire retardant plastic
Dimensions 4.5” x 3.8” x 1.25” (11.4 cm x 9.7 cm x 3.2cm)
Weight 2 lbs, .9 Kg
Regulatory FCC/CE, RoHS
Warranty Two (2) years
Order Information 500140: Active VGA Balun II Kit
500142: Active VGA Balun II, Receiver Only (Display), No PSU
500144: Power Supply 100-240V/12VDC/.5A for 500142
