© MuxLab Inc. Active VGA Balun II Family Installation Guide
Page 12
9. The following table provides suggested DIP switch
settings for Gain adjustments.
GAIN settings
(switches 4, 5 & 6)
Actual gain or loss
000 -50%
001 -35%
010 -15%
011 0%
100 +15%
101 +35%
110 +45%
111 +50%
Table 1: DIP switch settings for Gain adjustment
10. The following table provides suggested DIP switch
settings for equalization adjustments.
EQUAL
settings
(switches 1, 2 & 3)
Distance (ft)
(resolutions up to
1024x768)
Distance (ft)
(resolutions above
1024x768)
000 Up to 200ft Up to 200ft
001 200ft to 350ft 200ft to 350ft
010 350ft to 600ft 350ft to 500ft
011 600ft to 800ft 500ft to 650ft
100 800ft to 900ft 650ft to 750ft
101 900ft to 1000ft 750ft to 800ft
110 900ft to 1000ft 800ft to 900ft
111 1000ft + 900ft to 1000ft +
Table 2: DIP switch settings for Equalization adjustment
Note: For display equipment with automatic gain control (for example,
certain models of projectors), complete all installation procedures and
ensure that all DIP switches are OFF before turning the display
equipment on. Otherwise, the display could override the adjustable
gain feature of the VideoEase Active VGA Balun Kit.
