NOTE:
These recommendations will provide optimal protection against EMI and RFI. The actual cable type, wire
gauge, shield type and filtering devices used are dependent on the customer’s application and system.
Driver Supply Cable AWG Table
1 Amp (Peak)
Length (Feet)
10
25
50*
75*
100*
Minimum AWG
20
20
18
18
16
2 Amps (Peak)
Length (Feet)
10
25
50*
75*
100*
Minimum AWG
20
18
16
14
14
3 Amps (Peak)
Length (Feet)
10
25
50*
75*
100*
Minimum AWG
18
16
14
12
12
* Use the alternative methods illustrated in Examples B and C
when the cable length is ≥ 50 feet. Also, use the same current
rating when the alternate AC power is used
Driver Supply Cable Wire Size
NOTE: Always use Shielded/Twisted Pairs for the Driver DC Supply Cable, the AC Supply Cable and the Driver to
Motor Cable.
