Configure the R325P using the DIP Switch
R325P DIP Switch Settings
Run Current
Function
SW1
SW2
SW3
SW4
0.3A
ON
ON
ON
ON
0.4A
OFF
ON
ON
ON
0.5A
ON
OFF
ON
ON
0.6A
OFF
OFF
ON
ON
0.8A
ON
ON
OFF
ON
1.0A
OFF
ON
OFF
ON
1.2A
ON
OFF
OFF
ON
1.4A
OFF
OFF
OFF
ON
1.6A
ON
ON
ON
OFF
1.8A
OFF
ON
ON
OFF
2.0A
ON
OFF
ON
OFF
2.2A
OFF
OFF
ON
OFF
2.4A
ON
ON
OFF
OFF
2.6A
OFF
ON
OFF
OFF
2.8A
ON
OFF
OFF
OFF
3.0A
OFF
OFF
OFF
OFF
Table 6.3
WARNING: Current of 2.7 Amp and above REQUIRES an additional heat sink; make sure the
temperature of the bracket does not exceed 45° C
Hold Current (Percent of Run Current)
Function
SW5
SW6
0%
ON
ON
33%
OFF
ON
66%
ON
OFF
100%
OFF
OFF
Table 6.4
Step Resolution
Function
SW7
SW8
SW9
SW10
Full Step*
OFF
OFF
OFF
OFF
2X
ON
OFF
OFF
OFF
4X
ON
ON
OFF
OFF
8X
ON
OFF
ON
OFF
16X
ON
ON
ON
OFF
32X
ON
OFF
OFF
ON
64X
ON
ON
OFF
ON
128X
ON
OFF
ON
ON
256X
ON
ON
ON
ON
*The power must be turned OFF when switching in and out of Full Step mode.
Table 6.5
RMS Technologies
Page 11
Version 1.01
R325PE Single Axis Closed loop Driver/Indexer Manual
5/29/2013
