Condition for OUT2 to turn off.
0 0 0 0 : Set points do not turn off OUT2.
1 1 1 1 : Turns off when the condition that
turned it on is not valid anymore
(see parameter
out2.se out2.se out2.se out2.se ).
0 0 0 0 : External reset does not affect
OUT2.
1 1 1 1 : Turns off at the start of an external
reset pulse.
2 2 2 2 : Turns off at the end of an external
reset pulse.
3 3 3 3 : Turns off at the start of an external
reset pulse.
0 0 0 0 : OUT1 does not affect OUT2.
1 1 1 1 : Turns off when OUT1 is turned on.
2 2 2 2 : Turns off when OUT1 is turned on.
3 3 3 3 : Turns off when OUT1 is turned on
or off.
out2.e out2.e out2.e out2.e
Out2 - End
0 0 0 0 : OUT2 ( out2.t out2.t out2.t out2.t ) time does not
affect OUT2.
1 1 1 1 : Turns off after the time in OUT2
Time parameter ( out2.t out2.t out2.t out2.t ) has
expired.
Effect of reset on the main counter.
0 0 0 0 : OUT2 does not affect the main
counter.
1 1 1 1 : Resets when OUT2 is turned on.
2 2 2 2 : Resets when OUT2 is turned off.
3 3 3 3 : Resets when OUT2 is turned on
or off.
0 0 0 0 : OUT1 does not affect the main
counter.
1 1 1 1 : Resets when OUT1 is turned on.
2 2 2 2 : Resets when OUT1 is turned off.
3 3 3 3 : Resets when OUT1 is turned on
or off.
0 0 0 0 : key does not affect the main
counter.
1 1 1 1 : key resets the main counter if
configured as reset.
0 0 0 0 : Remote reset does not affect the
main counter.
1 1 1 1 : Remote reset resets the main
counter.
res.c res.c res.c res.c
Reset Counter
0 0 0 0 : Set point 2 does not affect the
main counter.
1 1 1 1 : Resets the main counter when Set
point 2 is triggered.
Effect of reset on the batch counter.
0 0 0 0 : OUT2 does not affect the batch
counter.
1 1 1 1 : Resets when OUT2 is turned on.
2 2 2 2 : Resets when OUT2 is turned off.
3 3 3 3 : Resets when OUT2 is turned on
or off.
0 0 0 0 : key does not affect the batch
counter.
1 1 1 1 : key resets the batch counter if
configured as reset.
0 0 0 0 : Remote reset does not affect the
batch counter.
1 1 1 1 : Remote reset resets the batch
counter.
rES.bat rES.bat rES.bat rES.bat
Reset Batch
0 0 0 0 : Batch Set point does not affect the
batch counter.
1 1 1 1 : Resets batch counter when Batch
Set point 2 is triggered.
Effect of reset on the totalizer counter.
0 0 0 0 : OUT2 does not affect the totalizer
counter.
1 1 1 1 : Resets when OUT2 is turn on.
2 2 2 2 : Resets when OUT2 is turn off.
3 3 3 3 : Resets when OUT2 is turned on
or off.
0 0 0 0 : key does not affect the
totalizer counter.
1 1 1 1 : key resets totalizer counter if
configured as reset.
0 0 0 0 : Remote reset does not affect the
totalizer counter.
1 1 1 1 : Remote reset resets the totalizer
counter.
rES.tot rES.tot rES.tot rES.tot
Reset Totalizer
0 0 0 0 : Set point 2 does not affect the
totalizer counter.
1 1 1 1 : Resets totalizer counter when
Totalizer Set point is triggered.
Opt.sp.c Opt.sp.c Opt.sp.c Opt.sp.c
Option for Counter
Setpoint
Set point 1 reached.
0 0 0 0 : Actions corresponding to SP1 are performed when
the main counter becomes lower than or equal to
SP1 value.
1 1 1 1 : Actions corresponding to SP1 are performed when
the main counter becomes higher than or equal
to SP1 value.
Out1.op Out1.op Out1.op Out1.op
Out1 Option
Option that determines whether counting will be
frozen or not while OUT1 is triggered.
0 0 0 0 : Releases counting while OUT1 is triggered.
1 1 1 1 : Holds counting while OUT1 is triggered.
Out2.op Out2.op Out2.op Out2.op
Out2 Option
Option that determines whether counting will be
frozen or not while OUT2 is triggered.
0 0 0 0 : Releases counting while OUT2 is triggered
1 1 1 1 : Holds counting while OUT2 is triggered.
Out2.se Out2.se Out2.se Out2.se
Out2 Selector
Selects which Set point will enable OUT2.
0 0 0 0 : Main counter Set point 2.
1 1 1 1 : Batch counter set point.
2 2 2 2 : Totalizer set point.
HARDWARE CONFIGURATION CYCLE
Pass Pass Pass Pass
Password
Parameter that requires a password to be inserted in
order to enable changes on next parameters (see item
“Password”).
Accepts values from
0000 0000 0000 0000 to 9999 9999 9999 9999 .
Out1.c Out1.c Out1.c Out1.c
Out1 Contact
Definition of OUT1 normal mode.
0 0 0 0 : Relay (NO - closes contact when triggered).
1 1 1 1 : Relay (NC - opens contact when triggered).
Out2.c Out2.c Out2.c Out2.c
Out2 Contact
Definition of OUT2 normal mode.
0 0 0 0 : Relay (NO - closes contact when triggered).
1 1 1 1 : Relay (NF - opens contact when triggered).
Sens.ty Sens.ty Sens.ty Sens.ty
Sensor Type
Signal polarity applied to all inputs of NC400-6, it makes
possible to change hardware input settings according to
signal used.
0 0 0 0 : Sensor with open collector output NPN or dry contact.
1 1 1 1 : Sensor with open collector output PNP or pulse input.
coun.ty coun.ty coun.ty coun.ty
Counter Type
It define the input signal reading mode.
0 0 0 0 : slow reading speed. A filter is applied to inputs and
after a pulse is acknowledged it ignores for 9 ms any
following pulse in that input (it must be used in Dry
Contac signals). In quadrature counting modes
(
coUn.UP coUn.UP coUn.UP coUn.UP ≥ 12 12 12 12 ) this filter is ignored.
1 1 1 1 : fast reading speed. A filter is not applied to inputs.
