SCREENS
SCREEN TITLE FIGURE DESCRIPTION
FAVORITES
This screen shows
a six-position grid
where you can
assign a channel
to be displayed on
each position.
CHART
This screen
saves a log of the
favorite channels
values.
CHANNEL LIST
This screen
shows a list with
all FieldLogger
enabled channels
(analog, digital,
remote
and
virtual).
ALARMS
The “Alarms”
screen is 32-
position
grid
where each
numerated
position is related
to its equivalent
alarm.
STATUS
On this screen, a
list is shown with
information about
FieldLogger and
the HMI itself.
CONFIGURATION
Some
FieldLogger and
HMI parameters
can be changed
on this screen.
Table 01
H M I
(Human-Machine Interface)
Q U I C K G U I D E
QG 5000968
