Address
Description
Minimum
Maximum
R/W
SuperView
Mnemonic
10
Analog channel 8 value (signed 16-bit integer)
-32768
32767
R
Analog_8_Int
13
Bit array with the state of each digital I/O (bit 0: digital channel
1, bit 2: digital channel 2, etc.)
0
255
R
DigitalInArray
14
Digital input 1 state
0
1
R
DigitalIn_1_Int
15
Digital input 2 state
0
1
R
DigitalIn_2_Int
16
Digital input 3 state
0
1
R
DigitalIn_3_Int
17
Digital input 4 state
0
1
R
DigitalIn_4_Int
18
Digital input 5 state
0
1
R
DigitalIn_5_Int
19
Digital input 6 state
0
1
R
DigitalIn_6_Int
20
Digital input 7 state
0
1
R
DigitalIn_7_Int
21
Digital input 8 state
0
1
R
DigitalIn_8_Int
22
Digital output 1 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_1
23
Digital output 2 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_2
24
Digital output 3 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_3
25
Digital output 4 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_4
26
Digital output 5 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_5
27
Digital output 6 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_6
28
Digital output 7 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_7
29
Digital output 8 state (0 = deactivate, 1 = activate)
0
1
R/W
DigitalOut_8
30
Relay 1 state (0 = deactivate, 1 = activate)
0
1
R/W
Relay_1
31
Relay 2 state (0 = deactivate, 1 = activate)
0
1
R/W
Relay_2
32
Remote channel 1 value (signed 16-bit integer)
-32768
32767
R
Remote_01_Int
33
Remote channel 2 value (signed 16-bit integer)
-32768
32767
R
Remote_02_Int
34
Remote channel 3 value (signed 16-bit integer)
-32768
32767
R
Remote_03_Int
35
Remote channel 4 value (signed 16-bit integer)
-32768
32767
R
Remote_04_Int
36
Remote channel 5 value (signed 16-bit integer)
-32768
32767
R
Remote_05_Int
37
Remote channel 6 value (signed 16-bit integer)
-32768
32767
R
Remote_06_Int
38
Remote channel 7 value (signed 16-bit integer)
-32768
32767
R
Remote_07_Int
39
Remote channel 8 value (signed 16-bit integer)
-32768
32767
R
Remote_08_Int
40
Remote channel 9 value (signed 16-bit integer)
-32768
32767
R
Remote_09_Int
41
Remote channel 10 value (signed 16-bit integer)
-32768
32767
R
Remote_10_Int
42
Remote channel 11 value (signed 16-bit integer)
-32768
32767
R
Remote_11_Int
43
Remote channel 12 value (signed 16-bit integer)
-32768
32767
R
Remote_12_Int
44
Remote channel 13 value (signed 16-bit integer)
-32768
32767
R
Remote_13_Int
45
Remote channel 14 value (signed 16-bit integer)
-32768
32767
R
Remote_14_Int
46
Remote channel 15 value (signed 16-bit integer)
-32768
32767
R
Remote_15_Int
47
Remote channel 16 value (signed 16-bit integer)
-32768
32767
R
Remote_16_Int
48
Remote channel 17 value (signed 16-bit integer)
-32768
32767
R
Remote_17_Int
49
Remote channel 18 value (signed 16-bit integer)
-32768
32767
R
Remote_18_Int
50
Remote channel 19 value (signed 16-bit integer)
-32768
32767
R
Remote_19_Int
51
Remote channel 20 value (signed 16-bit integer)
-32768
32767
R
Remote_20_Int
52
Remote channel 21 value (signed 16-bit integer)
-32768
32767
R
Remote_21_Int
53
Remote channel 22 value (signed 16-bit integer)
-32768
32767
R
Remote_22_Int
54
Remote channel 23 value (signed 16-bit integer)
-32768
32767
R
Remote_23_Int
55
Remote channel 24 value (signed 16-bit integer)
-32768
32767
R
Remote_24_Int
56
Remote channel 25 value (signed 16-bit integer)
-32768
32767
R
Remote_25_Int
57
Remote channel 26 value (signed 16-bit integer)
-32768
32767
R
Remote_26_Int
58
Remote channel 27 value (signed 16-bit integer)
-32768
32767
R
Remote_27_Int
59
Remote channel 28 value (signed 16-bit integer)
-32768
32767
R
Remote_28_Int
60
Remote channel 29 value (signed 16-bit integer)
-32768
32767
R
Remote_29_Int
61
Remote channel 30 value (signed 16-bit integer)
-32768
32767
R
Remote_30_Int
62
Remote channel 31 value (signed 16-bit integer)
-32768
32767
R
Remote_31_Int
