189
Initialize Start
Control Mode
Change
16.6 Cascade Individual Assignment
In case of VC-C50i controlled individually, it is necessary to assign Device Number
Host
VC-C50i 1st unit 2nd unit 3rd
unit
(1) System Control Command
Cascade ON
(2)
Answer (ACK)
(3) System Control Command
Extended Operation Status Request
(to 1st unit)
(4) Answer (ACK + Status)
(5) System Control Command
Extended Operation Status Request
(to 2nd unit)
(6) Answer (ACK + Status)
(7)
Pedestal Control Command
Pedestal Initialize 1 (1st unit)
(8)
Answer (ACK)
Corresponding Frame Code
Command/Answer
(1) FF 30 30 00 8F 31 EF
(2) FE 30 33 30 30 EF
(3) FF 30 31 00 86 30 EF
(4) FE 30 31 30 30 33 30 30 31 30 EF
(5) FF 30 32 00 86 30 EF
(6) FE 30 32 30 30 33 30 30 31 30 EF
(7) FF 30 31 00 58 30 EF
(8) FE 30 31 30 30 EF
