Vaddio Canon VC-C50i Programmers - Manual (Page 146)

145
14.17 Operation Status 4 Request
System Control Command Type 1
Function Returns operation status 4.
Command 0086h
Parameter 2h
Length 2
byte Status
Value value of operation status which indicates inside status
(8 bits).
Reference The followings show status, in case that each bit is 1 among of status.
(MSB)
b7 Blink bit 4
b6 Blink bit 3
b5 Blink bit 2
b4 Blink bit 1
b3 Not used (undetermined value)
b2 Not used (undetermined value)
b1, 0 Color bit b1 b0
0 1 : Green LED
1 0 : Red LED
1 1 : Orange LED
(LSB)
Flashing bit pattern
b07 b06 b05 b04 Status
1 1 1 1 Always on
1 1 1 0 6s flashing
1 1 0 1 5s flashing
1 1 0 0 4s flashing
1 0 1 1 3s flashing
1 0 1 0 2s flashing
1 0 0 1 1.5s flashing
1 0 0 0 1s flashing
0 1 1 1 0.8s flashing
0 1 1 0 0.6s flashing
0 1 0 1 0.5s flashing
0 1 0 0 0.4s flashing
0 0 1 1 0.3s flashing
0 0 1 0 0.2s flashing
0 0 0 1 0.1s flashing
0 0 0 0 Off
Format of Control Code
d0 d1 d2 d3 d4 d5 d6
Header Device Num Command Parameter End mark
FFh 30h 3Xh 00h 86h 32h EFh
