111
13.49 Camera Reset Camera Control Command Type 2
Function To camera reset operation
Command 00AAh
Parameter None
Status None
Reference •To stop executing another operation of camera (except preset move) and
to force to set in initialized status regardless of pedestal initialize.
•Not to accept camera command during executing Camera Reset.
•To set in status of Focus Automatic, Zoom Stop, Auto White Balance
Normal, Fade Normal, Shutter Speed Program, Backlight
Compensation OFF, Exposure Auto, IR Filter ON and IR LED Light
OFF.
•To return notification at the moment of setting command termination
notification ON, when command normal finishes.
Format of Control Code
d0 d1 d2 d3 d4 d5
Header Device Num Command End mark
FFh 30h 3Xh 00h AAh EFh
Answer Format
d0 d1 d2 d3 d4 d5
Header Device Num Error Code End mark
FEh 30h 3Xh e0 e1 EFh
⇓
Error Flag indicates in 2 figures hexadecimal and returns ASCII code value.
Example: e0 e1
In case of No Error :
00000000B ⇒ 00h ⇒ 30h 30h
In case of Busy : 00010000B ⇒ 10h ⇒ 31h 30h
In case of Mode Error : 10010000B ⇒ 90h ⇒ 39h 30h
Condition of Error flag to be set
Busy •In process of camera initializing operation by Camera Reset
command, etc.
•In case of executing Preset Move command.
Mode Error •Not in status of Camera ON.
•Not in status of Host Control Mode.
