Page 92
Appendix A: Command Line Interface Access
A-4
5
In the COM1 Properties dialog, enter the Port Settings as follows:
• 9600 baud
• 8 data bits
• no parity
• 1 stop bit
• flow control off (none)
6
Click OK.
7
Press ENTER. A prompt will be displayed (see
); enter your login and password.
Figure A-3. Login Prompt
The System Management main menu is displayed (
Figure A-4. System Management Main Menu
Type the number and press ENTER to access the configuration menu for each parameter (WAN Session
Management or LAN Management, for example). Press ENTER (
higher-level menu.
Step
Action
Modem Defaults
Login
admin
Password
password
