Page 52: Step 3
Chapter 5: Configuring System Parameters
5-10
C
HANGE
S
PANNING
T
REE
S
ETTING
Spanning tree eliminates loops in a LAN topology, ensuring there is only one path (or link) between any two nodes in
a bridged network. Use spanning tree protocol (STP) when RFC 1483-Bridge protocol is assigned to either or both
of the following:
• WAN sessions (see
“Configure a New WAN Session” on page 4-2
• LAN port and the LAN has more than one device (PCs and servers, for example) and those devices have more
than one physical path connecting them.
3
To modify or delete an SNMP community, do the following:
a. From the SNMP Community List table, select the SNMP community Name. The following dialog is
).
Figure 5-10. Delete SNMP Community
b. Do one of the following:
– Change the Access Privilege, then click Apply.
– Click Delete to remove the static SNMP community.
Step
Action
