Operation

512680

Step 6: Start Dryer

To start dryer, push START pad.
To stop dryer at any time, open the door. To restart the

dryer, close door and push START pad.
Cycle is completed when time remaining reaches

00 minutes.

Figure 71

Indicator Lights

INSERT COINS/CARD
INSERT COINS/CARD is lit to prompt the user to

insert coins or a card to satisfy the vend price. When

INSERT COINS/CARD is lit, the three digits and

decimal point will display the vend price remaining to

be satisfied.
START
START is lit whenever the dryer is not in a cycle, the

full vend price has been satisfied and the dryer door is

closed. When the START pad is pressed, the cycle

will begin or resume.
DRYING
DRYING is lit to indicate that one of the heated cycles

(HIGH TEMP, MED TEMP, or LOW TEMP) is

currently in operation. DRYING will turn off at the end

of a heated cycle or when the COOL DOWN cycle

begins.
COOL DOWN
COOL DOWN is lit whenever the COOL DOWN

portion of a heated cycle is active. It is also lit when

the NO HEAT cycle is in operation.
ADD TIME (Card Models Only)
ADD TIME flashes when a card is inserted while a

cycle is running or when a card is left in the reader for

at least five seconds after cycle has started.
REMOVE CARD (Card Models Only)

REMOVE CARD flashes when a card is inserted or left

in the reader after a transaction is complete. It will also

flash alternately with ADD TIME when a card is

inserted while a cycle is running or when a card is left

in the reader.
