Setting
AUX FUNCTION screen
Item Functions and settings
AUX MODE This item sets the signal input or output of the AUX
terminal.
B&W OUT : A signal is output when the camera switches
to B&W or Color mode.
IR IN : Depending on the input signal of the AUX
terminal, the camera can switch between
B&W and Color mode. When there is an
alarm input, the mode will be B&W.
T When the INPUT POLARITY item of the AUX
FUNCTION is AMAKEB
When the contact is short (MAKE), the mode is B&W.
When the contact is open (BREAK), the mode is
Color.
T When the INPUT POLARITY item of the AUX
FUNCTION is ABREAKB.
When the contact is open (BREAK), the mode is
B&W.
When the contact is short (MAKE), the mode is Color.
[Default setting: B&W OUT]
