FEATURES

The ADC780 Series of pre-packaged vandal

resistant cameras is designed for tough

environments where a typical camera would not

survive. The housing is made of heavy-duty cast

aluminum with a polycarbonate viewing

window. The camera inside is protected by the

housing’s unique tamper resistant hardware.

For the surface dome and corner mount

versions, an overlapping cover with a gasket is

designed to protect against water intrusion.

With the optional thermostatically controlled

heater, the camera will operate in temperatures

from –40º to 50º C (-40º to 122º F). The heater

is not available with the flush mount version.

The installed camera is a high-resolution color

camera with 480 lines of resolution and a

2.6-6 mm variable focal, auto iris lens. This one

camera will meet or exceed most viewing

requirements, providing a sharp picture with

true colors.

These packages are ideal for schools, parking

garages and correctional facilities where

cameras are subject to abuse.

ADC780

VANDAL RESISTANT CAMERA
PRE-PACKS

Vandal resistant

Surface dome, flush
dome and corner mount
housings

Indoor and outdoor
versions

Tamper resistant
fasteners

Cast aluminum with
polycarbonate window

480-line color camera,
installed

2.6-6 mm variable focal
lens

Auto iris

Weather resistant
(outdoor version)

Backlight compensation

Heater options

Easy to install
