iCLASS Card Programmer Quick Start Guide – 3150-902
1. Select the file path designated for this installation.
Note: These files will be supplied on a 3 ½” disk; however they may also be provided by email.
2. Browse to the file location and click Load Files.
3. Click Exit.
2.2 Administrator Logon
When first logging onto the software, you must use the default User Name and Password as
shown:
Default Login:
Administrator
(Case Sensitive)
Default Password:
HID
(Case Sensitive, may be modified)
CAUTION: The first task the iCLASS Card Programmer Administrator should perform is the
creation of at least one Operator. Any person whose duty is the programming of cards and
the printing of cards or labels should be assigned an Operator role.
The User Name and Password must be entered each time the program is opened.
2.3 Communication Port
Note: If you have a bioCLASS Card Programmer (a unit with the fingerprint reader attached) you
have the option of using either USB or one of the RS-232 ports. By default these units are shipped
with a USB cable.
Note: The Baud Rate of 57,600 is the default at this time.
1. Click Tools > Port Settings.
2. Select the port to be used. USB is the default port.
3. Click Test Port to activate the port. The program will attempt to open the selected port, and
communicate with the iCLASS Card Programmer.
4. Click Save. This selection will be the default selection after the initial setup. If you change
the port location of the iCLASS Card Programmer, the port setting must be re-initiated.
5. Click Cancel to exit without changing the port setting.
There are two possible conditions that will result:
• Failed to open communication port – The selected port is either not installed,
enabled, or is being used by another device. The Port Status box will be red.
• OK – The selected port is open, and an iCLASS Card Programmer responded. The
Port Status box will be green. The type of iCLASS Card Programmer hardware is
displayed in the lower text box.
Note: If the status message indicates an error, or the iCLASS Card Programmer did not respond;
verify that you have the iCLASS Card Programmer connected to the corresponding port. Select the
port > click Test Port.
2.4 Uninstalling the Software
The iCLASS Card Programmer software may be removed from the hard drive with the Windows
Add/Remove Programs function located on the Control Panel. Next, delete the iCLASS Card
Programmer folder located under C:\Program Files\HID.
