Specifications – Nikon D1 User Manual

Page 136

123

Specifications

Type:

Single-lens reflex digital camera with interchangeable lenses

Operating environment

Temperature:

0 – 40

C (32 – 104

Humidity:

Less than 85% (no condensation)

Image sensor:

23.7

15.6 mm, 12-bit RGB CCD with 2.7 million pixels, effec-

tive pixel count 2.66 million pixels (2,012

1,324 pixels)

Image size:

2,000

1,312 pixels

Sensitivity:

200, 400, 800, 1600 (ISO equivalent)

Storage

Compression:

JPEG baseline-compliant (approximate compression ratios
1:4, 1:8, 1:16); uncompressed files recorded as YCbCr-TIFF (8-
bit), RGB-TIFF (8-bit), or RAW data (12-bit)

File system:

Design Rule for Camera File Systems, Digital Print-Order
Format (DPOF) compliant

Media:

CompactFlash card (Type I/II)

Capacity:

Approx. 66 images at an image quality of FINE, 132 images at
NORMAL, 265 images at BASIC, 18 images at HI/YCbCr-TIFF,
12 images at HI/RGB-TIFF, 23 images at HI/RAW (all figures for
96 MB memory card)

Operating modes:

S (single frame shooting, capture-preview and record-and-
review modes available)
C (continuous shooting, approx. 4.5 fps, max. 21 consecutive
shots)

(self-timer mode; delay can be specified by user)

PLAY (playback mode with playback menu)
PC (data transfer mode; camera can be controlled from com-
puter)

White balance:

Auto (TTL control with 1,005-pixel CCD)
Six manual modes, adjustable from –3 to +3 in 7 steps
Preset

LCD monitor:

2-inch, low temperature polysilicon TFT, 114,000 pixels, ad-
justable brightness

The left and right edges of photographs are not shown when the
photographs are displayed in the LCD monitor

Playback function:

Single-frame playback, thumbnail playback (9 images),
slideshow, histogram, and highlight point display

Delete function:

Card format, delete all images, delete selected images

Video output:

NTSC or PAL (selectable)

External interface:

IEEE 1394 (400Mbps)

Technical Notes: Specifications
