I. TUBE
ROUTING
The following table contains examples on how to establish connections between the different elements of a cooling circuit based on multiple
possible configurations. This table assumes that the fill-and-bleed kit is positioned at the uppermost position in the computer, and that the pump is
located at the lowermost location.
These are guidelines only, and may change depending on the relative position of the components inside your chassis.
Devices: (1) CPU Cooler + (1) Radiator + Pump + F&B kit
Fill & bleed
discharge
to pump
inlet
Pump
discharge
to CPU
cooler inlet
CPU cooler
discharge
to radiator
inlet
Radiator
discharge
to fill &
bleed inlet
– Loop
completed
Devices: (1) CPU Cooler + VGA cooler + (1) Radiator + Pump + F&B kit
Fill & bleed
discharge
to pump
inlet
Pump
discharge
to VGA
cooler inlet
VGA cooler
discharge
to CPU
cooler inlet
CPU cooler
discharge
to radiator
inlet
Radiator
discharge
to fill &
bleed inlet
– Loop
completed
Devices: (1) CPU Cooler + VGA cooler + Chipset cooler + (1) Radiator + Pump + F&B kit
Fill & bleed
discharge
to pump
inlet
Pump
discharge
to VGA
cooler inlet
VGA cooler
discharge
to Chipset
cooler inlet
Chipset
cooler
discharge
to CPU
cooler inlet
CPU cooler
discharge
to radiator
inlet
Radiator
discharge
to fill &
bleed inlet
– Loop
completed
Devices: (1) CPU Cooler + VGA Cooler + Chipset Cooler + (2) Radiators + Pump + F&B kit
Fill & bleed
discharge
to pump
inlet
Pump
discharge
to VGA
cooler inlet
VGA cooler
discharge
to Chipset
cooler inlet
Chipset
cooler
discharge
to CPU
cooler inlet
CPU cooler
discharge
to Y
connector
for
PARALLEL
connection
to both
radiator
inlets
Dual
Radiator
discharges
to Y
connector
to fill &
bleed inlet
– Loop
completed
Devices: (2) CPU Coolers + VGA cooler + Chipset cooler + (2) Radiators + Pump + F&B kit
Fill & bleed
discharge
to pump
inlet
Pump
discharge
to VGA
cooler inlet
VGA cooler
discharge
to Chipset
cooler inlet
Chipset
cooler
discharge
to CPU #2
cooler inlet
CPU #2
cooler
discharge
to CPU #1
cooler inlet
CPU #1
cooler
discharge
to Y
connector
for
PARALLEL
connection
to both
radiator
inlets
Both
radiator
discharges
to Y
connector
to fill &
bleed inlet
– Loop
completed
